How To Lnstall Drawer Runners

How To Lnstall Drawer Runners


Take Aolisheng 53MM wide drawer Runners rail with lock as an example


AOLISHENG Heavy Duty Locking Drawer Runners D2053, 1pair


1. First prepare the tools and materials:

Installing the drawer runners requires tools such as a screwdriver, drill, ruler, pencil, cork, the drawer runners itself and a wooden board that matches the size of the drawer.

2. Measure the size of drawers and boards:

To install the drawer runners, you need to first measure the size of the drawer and the corresponding wooden board, make sure the length and width of the drawer runners match, use a ruler and pencil to mark the installation position on the drawer and wooden board, make sure the drawer runners are in the correct position Location.

3. Take out the drawer runners rail with lock:

Press the lock handle to unlock the runners rail, press the lock handle again to separate the inner rail

4. Install the outer rail:

Secure the outer rail to the side of the furniture, making sure it is level and the guides on both sides are parallel, place the drawer runners in the marked positions and screw the drawer runners in using a screwdriver and power drill.

5. Install the inner rail:

Fasten the inner rails to the drawer side panels. Make sure the inner and middle rails are aligned, and pull the bead holder over the top of the middle rail, making sure the drawer and the rack can slide freely between them. Use M5 screws to fix the inner rail to the side panel of the drawer.

6. Test slide rail:

Place the pump on the slide and test for smooth movement. The position of the rails can be fine-tuned if desired.

The installation is complete:

After the installation is complete, test again that the extraction can be turned on and off smoothly. Note that the load-bearing capacity of this extraction runners is 120KG, so there is no need to be stingy.

Heavy Duty Locking Drawer Runners D2053

Drawer Runners Maintenance
  •  Keep slides clean: Use a soft cloth or brush to remove any dust or debris from runners.
  • Lubricate slides: Apply a lubricant, such as a silicon-based spray, to slides to help them glide smoothly.
  • Tighten loose screws: Check the screws that secure the runners rails to the cabinet or drawer and tighten any loose screws.
  • Check for Damage: Periodically inspect the runners rails for signs of wear or damage, and replace any damaged or worn parts.
  • Avoid Overloading Drawers: Overloading drawers can stress the slide rails and cause damage or failure.

Frequently Asked Questions

What are the different types of drawer runners?

 Kind tips

  •  Proper maintenance of your drawer slides will help ensure their longevity and prevent problems such as sticking, squeaking, or not closing properly.
  • The type of drawer slides you choose will depend on your specific needs and preferences, so it's important to do your research and choose a product that meets your requirements. It's also a good idea to consult the manufacturer and a professional if you're not sure what to choose.
